AC500 Ceiling System

The panels for this system are constructed from sustainable steel or aluminium, and there’s a choice of expanded mesh pattern.

The AC500 can be supplied with optional black fleece acoustic infills to help reduce noise in busy environments.

Powder coating is the standard finish for this system, and the colours include White (RAL 9010), Silver (RAL 9006) and Black (RAL 9005).

Downloads

Contact Sales

An orange AC500 ceiling in a white, open plan workspace

Downloads

Contact Sales

System Features.

EXPOSED GRID

UP TO 1.0 NRC

A2, s1, d0

RECYCLABLE

25YR WARRANTY

Technical Details.

Amron’s expertise ensures your panels integrate seamlessly into your design, with precise planning and guidance for a flawless installation.

A AC500 90’ Corner splice bracket
B Clevis Cleat support bracket
C AC500 Aluminuim 25x35mm T-bar grid
D Threaded rod suspension hanger
E AC500 T-Bar connect to US trim bracket
F AC500 US50 Aluminuim perimeter floating edge trim
G AC100 expanded mesh lay in tile, 590x590mm
H US50 – 50 X 19 Aluminium extruded floating edge perimeter trim
I Inner 90’ Corner splice bracket with grub screw tightening detail
J M6 Clevis cleat and threaded rod suspension detail
K 35 x 25mm Aluminium T-grid extrusion

System Overview.

Grid

Available with Aluminium perimeter upstands with interconnecting Aluminium T-grid

Size

Set kit sizes up to 1200mm x 2400mm, based on 600mm x 600mm modules

Material

Steel

Types

Expanded Mesh

Finish

Polyester powder-coated (PPC)
Electroplated (Luxe Finish)
Bespoke finishes on request

Acoustic

Acoustic fleece, pad or board
Performance is dependant on pattern open area and infill
Absorption: up to 1.0NRC
Attenuation: up to 40dB

Fire

A2, s1,d0 dependant on finish

Services

Services independently suspended

Environmental

ISO 14001 and ISO 9001
Recyclable and designed for disassembly and repurpose

Finish Options

Choose a finish for your ceiling system that suits your design. We offer a wide range of finishes that allow you to create a bespoke ceiling that meets your client’s requirements and fulfils the design goals of the project.

Explore The Finishes

Metal Types

Our metal types collection features a large variety of mesh and metal, including perforated metal, expanded mesh and woven mesh. We have carefully curated the metal, mesh and patterns which we believe complement each system.

Browse Patterns and Types
